Outdoor unit installation
Standard accessories
Please check the attachment is complete, please be sure to use.
No. denition Graphic Quantity Remarks
Place
position
1
Installation
instruction
1
Accessory
bag
4
Rubber
plug
1
Signal line
protection
Accessory
bag
5 sheath
1
Power line
protection
Accessory
bag
6
Reducing
pipe
Reducing pipe
Accessory
bag
7
wiring
harness
4
Gas liquid pipe
insulation binding
Accessory
bag
8 Wrench
1
Remove service
panel
The outdoor
machine foot
beam
1. Choose a place that can carry the weight of the unit to install and x, so that the unit will not shake or fall. The
unit shall be installed in a at area (below 1/100).
2. Do not install the unit in the areas where there may be ammable, explosive, corrosive gas leakage.
3. Indoor and outdoor machines should be close to each other as much as possible to reduce the length of the
refrigerant pipeline and the number of bends.
4. The installation should be to ensure that units from the sun and rain, dust, typhoon, earthquake proof place.
In the area of snow, the machine should be installed in the frame or under the snow cover, so as to avoid the
machine snow. See Figure 1
5. Make sure that there is enough room for maintenance
6. Measures should be taken to avoid contact with children
7. The refrigerant pipe by the unit below should be used when the overhead, overhead part height 200mm above.
See Figure 2
Snow cover (customer buy)
Wind shield (the customer at
his own expanse)
Seasonal wind
The base height should be
considered the maximum
snowfall locally, Prevent snow
height exceeds the unit angle.
Please use M12 xed ancher bolts, each machine 4, and use
shock absorbers or cusions to reduce noise
Aerial part
height above
200mm
Figure 2Figure 1
(8HP)
2
2
2
(10HP)
2
2
1
(12~14HP)
2
1
(16~22HP)
1
