71
˃300mm
˃300mm
˃1000mm
˃200mm
Place with air inlet hole
Notes:
a. Fan speed Vs at air inlet is 1.5m/s or below.
b. Air outlet height HD=H-h and below 1m.
˃300mm
˃300mm
˃1000mm
˃200mm
H
HD
h
External air
duct
˃1000mm
3. Wall higher than the outdoor condenser
