HAIMA M3 Series User Manual

Overview I-3
Linear Sizes
 The linear sizes refer to the actual sizes between
two standard points.
 The standard points and sizes are symmetric with
respect to the center of the vehicle, unless
otherwise specified.
Example:
The sizes are different between left and
right sides with respect to center of vehicle.
Symbol
The following 8 symbols are used to indicate standard points.
Symbol Meaning Symbol Meaning
Center of round hole Port and gap of steel plates
Center of elliptical hole
Bolt pin
Edge of hole Center of rectangular hole
Groove Edge of rectangular hole
