Figure 7 Figure 10
Figure 8
Figure 9
These Additional Parts Are Available From Haldex
Adjustable Linkages:
48100374 -- Looped Linkage Max. Length 16”
48100375 -- Looped Linkage Max. Length 22”
48100367 -- Strap Linkage Max. Length 14”
48100224 -- Fixed Rod Linkage Max. Length 15 7/8”
Upgrade your Pressure Protection Valve to include an inline
filter:
90554107 -- PPV With Inline Filter
Add a suspension dump feature to your truck or trailer:
90554088 -- For Switch to Pilot Manual Dump
Valves
90554615 -- For Remote Mounted “Auto” or
Manual Dump Applications
