Always adhere to the dimensions shown in the table. If you’re in any doubt please contact the retailer.
6Nm6Nm
X
Y
4
5
Brand Model Year Door X Y A B
AUDI Sportback 2004->2013 5 97 cm 93 cm 16.5cm 68 cm
VW Polo IV 2001->2009 3 91 cm 89 cm 23.5 cm 76 cm
VW Polo IV 2001->2009 5 91 cm 90.5 cm 23.5 cm 74 cm
VW Polo V 2009->2017 5 97.5 cm 94 cm 30 cm 77 cm
FORD Fiesta 2018-> 5 97 cm 95 cm 21 cm 65 cm
(See fig 7 & 8)
