USA-CAN - 32

Check whether or not the holes for the
upper and lower spray arms are clogged.
If there is any clogging, remove the spray
arms and clean them under water.
You can remove the lower spray arm by
pulling it upwards, while the upper spray
arm nut can be removed by turning the nut
to the left.
Be sure that the nut is perfectly tightened


Clean the impellers at least once a week in
󰀩

Check if the holes on the lower impeller (1
are clogged. If they are clogged, remove
and clean the impeller. Pull the lower
impeller up to remove it (A, B.)
