MEMCO LTD, CLYDE HOUSE
REFORM ROAD, MAIDENHEAD
BERKS SL6 8BY, UK
TELEPHONE: +44 1628 770734
FACSIMILE: +44 1628 621947
www.memco.co.uk
DSHEET13/SPA/24.03.2011
618 SPECIFICATION
Detector size 9mm (
3
/
8
") x 37.3mm (1
1
/
2
") x 2008mm (6' 7
1
/
16
")
Fixing kit 10 x 6mm ‘P’ Clip
10 x No.6 x 20mm CSK screws
12 x No.8 12mm S/T screws
10 x No.6 16mm S/T Pan Head screws
10 x M3.5 shakeproof washers
2 x M4 shakeproof washers
Distance between bottom
beam and bottom of housing 20.5mm (
13
/
16
")
Distance between top
beam and bottom of housing 1834mm (6'
3
/
16
")
Range 4m
Number of diodes per detector 18
Distance between diodes bottom 4 diodes 58.5mm, top 14 diodes 117mm
Number of beams 81 when detectors are more than 650mm apart, 50 when less than 650mm
apart, 18 when detectors are closer than approx 250mm
Input Voltage 11-30V DC max @ 80mA max (excluding PNP load current). Supply must
have a ripple voltage of no more than 36V peak
Output Stage NPN or PNP transistor (factory set)
Indicators 2 red LEDs on TX (visible through the lens)
Light immunity >100,000 lux
Operating temperature range -10°C to 55°C as per BS2011 Part2.1 Ab and Part 2.2 Bb
Temperature storage -20°C & 65°C for 16 hours at each temperature
High temperature/high humidity BS2011:Part2.1Db:1981, Variant2 at +55°C
EMC compliance Emissions to EN12015, Immunity to EN12016
IP Rating IP54 in accordance with BS EN60529:1992
Sleep Software Patent Nos UK 9822359.7
Germany 29918009.3
Japan 291527/1999
USA 09/416,585
Ordering Information
Normal Product Range
618 180 Set of Model 618 Detectors each with 2.7m cable PNP-N/C output
618 180-B Set of Model 618 Detectors each with 4m cable PNP-N/C output
Available on Request
618 080 Set of Model 618 Detectors each with 2.7m cable NPN-N/C output
618 090 Set of Model 618 Detectors each with 2.7m cable NPN-N/O output
618 190 Set of Model 618 Detectors each with 2.7m cable PNP-N/O output
Accessories
280 000 Power Supply: 115/230V AC
281 000 Power Supply: 15-36V DC
616 800-010 Static Fixing Kit
This product is designed for use in elevators with powered automatic doors where the closing force
is 25N/mm or less as per EN81 requirements. It should be installed by qualified personnel only, therefore
any use outside of this application is at the installer’s own risk and should be assessed appropriately.
As a result of our policy of continual improvement, the information in this document is subject to change
without notice and it is intended only as general guidance on product performance and suitability.
This information shall not form part of any contract.
