CAN Hub Mini Configurations with RacePak IQ-3 Dash
The RacePak IQ-3 must be in the last position occupied on the CAN Hub Mini, that is
furthest away from the ECU.
ECU with RacePak IQ-3 ( No CAN Hub Mini Required)
ECU with 2 Devices (inc RacePak IQ-3)
Haltech CAN Hub Mini
Quick Start Guide
Congratulations on purchasing a Haltech Engine Management CAN Hub Mini.
This Plug and Play product allows you to expand the functionality of your ECU by
allowing the connection of other Haltech CAN based expansion devices.
This quick start guide will walk you through installation of the Haltech CAN Hub Mini into
a vehicle. This guide is accompanied by the full service manual located on the software
CD provided with the ECU that you or your tuner will need to refer to before completing
your installation and configuration. The manual can also be downloaded
from the Haltech website www.haltech.com
Included in Haltech CAN Hub Mini Kit
• Haltech CAN Hub Mini
• Haltech CAN Cable White (1 x 300mm)
• Quick start guide
Optional Accessories ( Sold Separately )
• CAN Cable Direct Connection Black / Black 75mm ( HT040050 )
• CAN Cable Hub Connection White / White 75mm ( HT040051 )
• CAN Cable Direct Connection Black / Black 150mm ( HT040052 )
• CAN Cable Hub Connection White / White 150mm ( HT040053 )
• CAN Cable Direct Connection Black / Black 300mm ( HT040054 )
• CAN Cable Hub Connection White / White 300mm ( HT040055 )
• CAN Cable Direct Connection Black / Black 600mm ( HT040056 )
• CAN Cable Hub Connection White / White 600mm ( HT040057 )
• CAN Cable Direct Connection Black / Black 900mm ( HT040058 )
• CAN Cable Hub Connection White / White 900mm ( HT040059 )
• CAN Cable Direct Connection Black / Black 1200mm ( HT040060 )
• CAN Cable Hub Connection White / White 1200mm ( HT040061 )
• CAN Cable Direct Connection Black / Black 1800mm ( HT040062 )
• CAN Cable Hub Connection White / White 1800mm ( HT040063 )
• CAN Cable Direct Connection Black / Black 2400mm ( HT040064 )
• CAN Cable Hub Connection White / White 2400mm ( HT040065 )
• CAN Cable Hub Connection White / White 3000mm ( HT040066 )
• CAN Cable Direct Connection Black / Black 3000mm ( HT040067 )
• CAN Cable Hub Connection White / White 3600mm ( HT040068 )
• CAN Cable Direct Connection Black / Black 3600mm ( HT040069 )
