Hama 118060 - Installation Kit and Tools; Required Tools for Mounting; Included Mounting Hardware Components

Required tools /benötigtes Werkzeug
10
Installation kit /Montagesatz
(A1) 6x55 (x4)
(D1) M8x12 (x4)
(A2) Ø10x50 (x4)
(D2) M8x20 (x4)
(D3) M8x30 (x4)
(A3) M6 (x4)
(D4) M8x45 (x4)
(B1) M6 (x4)
(E1) M4x12 (x4)
(B2) Ø8x10 (x4)
(E2) M4x20 (x4)
(B3) Ø8x20 (x4)
(F1) (x1)
(C1) M6x12 (x4)
(F2) (x1)
(C2) M6x20 (x4)
(F3) (x4)
1
2 3
60mm
F2
A3
A2
A1
F1
10
