Hammer Strength OHDHR - Step 4: Pull-up Support Installation

7
STEP 4:
FIGURE 4
• LOOSELY assemble the PULL-UP SUPPORT (8) to the REAR UPRIGHTS (4) using four 1/2 X 4-1/4” BOLTS (25), four 1/2” PLASTIC
DOME WASHERS (21), four 1/2” INT TOOTH LOCK WASHERS (19) and four 1/2” LOCK NUTS (22) as shown in FIGURE 4.
8
19
21
22
1/2 X 4-1/4” 25
4
4
