HAMPTON BAY GCS00180A - Assembly; Assembling the Swing Frame

As
1
s
semb
l
Assembling the swing frame
Attach two sets of the leg (B) to the top bar (A) using M8X102 bolts and nuts (AA).
ly
4
Attach the two connect bars (D) to the legs (B) and the top bar (A) using M8X102 bolts and nuts (AA).
Attach the two side bars (C) to the legs (B) using M6X40 bolts (DD).
A
B
B
B
B
C
C
D
D
BB
BB
AA
AA
DD
DD
