FIGURE 1
8
STEP 1 A-Frame Assembly
Spreader Arms
1
• On a level surface, carefully position the A-Frame so that it is standing upright and the
Stability Feet are on the ground.
• Gently push down on the Spreader Arms to ensure they are fully open and in the “locked”
position (Figure 1).
• Familiarize yourself with the Front, Back, Left and Right of the A-Frame. You may want
to refer back to this diagram for reference throughout the assembly process.
RIGHT Indicates right side as you are using the inversion table, not facing it.
LEFT Indicates left side as you are using the inversion table, not facing it.
BACK Indicates the back of the A-Frame / fully assembled inversion table.
FRONT Indicates the front of the A-Frame / fully assembled inversion table.
Crossbar
2
To Next Page
