Hanover 9820010 - Base Assembly; Base Assembly Inspection

7
Anchor Assembly
J1
1L
1R
J1
Q
H
J1
J1
J1
3
2R
2L
S4
J1
S4
PART
NO.
Qty.
Q 1
1
1
1R
2L
1
1
H
1L
1
2R
1
3
J1
8
S4
2
S4
F1 F1
F1
Base Assembly
10FT
1、When diagonal measurements are equal,the frame is
square.
Base Assembly Inspection
2、The Floor Frame must be BOTH square AND
level or the holes will not line up properly.
