HAPPATIO Gazebo - Page 14

11
Gazebo
M6X15MM Bolt
8PCS
X
1PC
T1
M6X15MM Bolt
16PCS
X
1PC
T1
...............................................................................................................................................................
STEP 14
STEP 13
U1
M1
X
U1
W1
Y2
Y1
Y1 Y2
W1 W2 W3 W4
W2 W3W4
X
U2
X
U1
U2
Note：
①The iron sheet contains sharp parts, please
wear gloves when installing.
②Prepare a relatively high ladder
and power tools, which will make your
installation easier and faster.
③Each iron plate has 2 holes. The holes near
the top need to be fixed on the frame
with screws, and the holes near the
bottom do not require any operation.
