HAPPATIO Gazebo - Page 19

16
Gazebo
M6X15MM Bolt
6PCS
X
1PC
T1
M6X15MM Bolt
36PCS
X
1PC
T1
...............................................................................................................................................................
STEP 24
STEP 23
R1
R1
R2
R2
V2
V1
M1
X
X
X
Note：
V1 and V2 are installed
from the inside,
installed on the top of
the big roof,
used to fix the iron sheet.
