Hardi HC 9500 User Manual

5 - Operation
5.15
Headland Types
All-Around
• Offset Implement Width
Number of implement widths used to set the
headland width.
• Offset Distance
Distance used to set headland width.
Press to accept.
Top Bottom
• Offset Implement Width
Number of implement widths used to set the
headland width.
• Offset Distance
Distance used to set headland width.
• Heading
Used to generate boundary, headlands are
created perpendicular to heading
• Scaling
Sets the amount of variation that is allowed
(from perpendicular) to include part of field
boundary in the headlands.
• Use AB
Select AB line to set heading for determining headlands.
• The shows the heading used for Headland creation.
Press to accept.
