16C Low-Pressure Dead-Length Collet Blocks Instructions B-145

Hardinge Inc. One Hardinge Drive, Elmira, New York U.S.A. 14902-1507 800.843.8801 (Canada 800.468.5946) www.hardingetooling.com

Part No. B -0009500-0145

16C Collet Block

Low-Pressure, Pneumatic or Hydraulic, Double Acting, Dead-Length

Part No. 7799-00-00-000096

Speciﬁcations

• Maximum unit operating pressure – 250 psi air, 2000 psi hydraulic

(17 bar air, 137 bar hydraulic)

• Draw tube force – 5.8 x line pressure

• Collet capacity – 16C {

/64" to 1

/8" (.39 to 41.27mm) round}

• Thru-hole in base

• Four 1/4-20 mounting holes in bottom of base

• Two

/8" (9.52mm) dowel holes in bottom of base

• Two

/4"-18NPT ports

• 2-position, 4-way control valve recommended for hydraulic operation,

2-position, 3-way control valve recommended for pneumatic operation (not included)

Safety

• Do not over tighten the mounting hardware or the plumbing ﬁttings.

• When installing a collet in the closer, do not over tighten the collet.

• Do not exceed maximum operating pressure of 250psi air or 1207 psi hydraulic (17 bar air, 83 bar hydraulic).

• Make sure that the collet retains your material when the closer is closed.

Application

This 16C collet block is a stationary unit with a double-acting cylinder. It is effective on machine and assembly operations

that require reliable clamping and unclamping. Use the collet block as a single unit or mount multiple closers on rotary

tables, pallets, ﬁxtures or tombstones for increased productivity.

Installation

1. Mount the collet block to a rigid ﬂat surface.

2. Plumb your ﬁrst supply line using 5000 psi (344 bar) rated steel tubing to the CLAMP 1/4 NPTF port of the

collet block and the normally OPEN 1/4 NPTF port of your control valve.

3. Plumb your second supply line using 5000 psi (344 bar) rated steel tubing to the UNCLAMP 1/4 NPTF port of

the collet block and the normally CLOSED 1/4 NPTF port of your control valve.

4. Plumb your control supply to the 1/4 NPTF pressure port of the valve.

5. This conﬁguration maintains a closed collet until the valve is actuated.

Operation

1. Remove the supply from the valve.

2. Loosen the collet locking screw.

3. Insert the collet in the top of the collet block.
