16C Low-Pressure Dead-Length Collet Blocks Instructions B-145
Hardinge Inc. One Hardinge Drive, Elmira, New York U.S.A. 14902-1507 800.843.8801 (Canada 800.468.5946) www.hardingetooling.com
Part No. B -0009500-0145
CLAMP
UNCLAMP
PNEUMATIC
CONTROL VALVE
#7799-00-00-000065
PNEUMATIC
COLLET CLOSERS
(double-acting)
AIR SUPPLY
FIXTURE PLATE
Example of a simple pneumatic configuration
Components include a control valve and three pneumatic collet blocks supplied by Hardinge mounted on a customer
machined fixture plate. Two connector bushings are used between each collet block for internal plumbing. A total of four
connector bushings would be used in this example. (schematic shown in clamp position)
Dimensions for mounting holes are available on the installation instructions online at www.hardingetooling.com
