20
Charging symbol not
displaying while panel
is in direct sunlight
Panel has been improperly
connected to the regulator
Check all connections and ensure
positive and negative battery
clamps are attached to the correct
terminals
Overvoltage protection has
enabled (the battery icon
will be flashing)
Disconnect the charging device /
solar from the regulator and
consult an auto electrician
Overtemperature protection
has enabled (the battery
icon will be flashing)
Locate the controller to a cooler
environment and allow it to cool
Load icon is off
(when load is
connected)
Battery voltage is low
Incorrect display option is
selected
Charge the battery
Select a display option where
load is displayed
Load icon
flashes slowly
The load connection is
drawing too much power
Turn load device to low setting if
applicable or replace.
Load icon
flashes quickly
Short circuit protection
System should automatically
reconnect
Short circuit protection
Reconnect the regulator, ensuring
terminals are connected correctly
Solar regulator does not
turn on
Battery not charged
sufficiently
Battery not connected
properly
Charge the battery
Check the battery’s connection to
the regulator
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
FRANÇAIS - PG 24 ESPAÑOL - PG 28
SPECIFICATIONS
NOTES
Membrane material 600D Ripstop polyester canvas
Panel material A-grade monocrystalline silicon solar cells
Maximum power 200W
Maximum voltage 21.5V
Maximum current 9.35A
Open circuit voltage 26.7V
Short circuit current 9.79A
Gross weight 17.9 lb / 8.1kg
Operating temperature (regulator) -40°F 122 °C / -40°C 50°C
Solar blanket dimensions (folded) 19.2in x 18.8in x 2.3in / 490mm x 480mm x 60mm
Solar blanket dimensions (open) 62in x 37in x 0.4in / 1595mm x 963mm x 12mm
Solar blanket weight 13.1 lb / 5.95kg
Regulator dimensions 5.2in x 2.7in x 1.3in / 133mm x 70mm x 34mm
Regulator weight 0.3 lb / 154g
FRANÇAIS - PG 25 ESPAÑOL - PG 29
