Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
3 CHANNEL AMP
R316 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R317 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R318 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R319 6044156016 1 PC RCF 560R0 OHM +5% 250MI0W
R320 5088296016 1 PC RCF 150R0 OHM +5% 250MI0W
R321 5088296016 1 PC RCF 150R0 OHM +5% 250MI0W
R322 5088296016 1 PC RCF 150R0 OHM +5% 250MI0W
R323 5088296016 1 PC RCF 150R0 OHM +5% 250MI0W
R324 5088301016 1 PC RCF 15K0 OHM +5% 250MI0W
R325 5088301016 1 PC RCF 15K0 OHM +5% 250MI0W
R326 2046946016 1 PC RCF 2K2 OHM +5% 250MI0W
R329 8043698016 1 PC RCF 620R0 OHM +5% 250MI0W
R332 5523277016 1 PC RMF 2R2 OHM +5% 500MI0W
R333 5523277016 1 PC RMF 2R2 OHM +5% 500MI0W
R334 5523278016 1 PC RMF 100R0 OHM +5% 500MI0W
R335 5523278016 1 PC RMF 100R0 OHM +5% 500MI0W
R336 5523279016 1 PC RMF 15R0 OHM +5% 500MI0W
R337 5523279016 1 PC RMF 15R0 OHM +5% 500MI0W
R340 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R341 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R342 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R343 5523281016 1 PC RMF 10R0 OHM +5% 500MI0W
R344 8043700016 1 PC RCF 1K2 OHM +5% 250MI0W
R345 8043700016 1 PC RCF 1K2 OHM +5% 250MI0W
R346 5088301016 1 PC RCF 15K0 OHM +5% 250MI0W
R347 2046949016 1 PC RCF 6K8 OHM +5% 250MI0W
R348 3093938016 1 PC RCF 22R0 OHM +5% 250MI0W
R349 3093938016 1 PC RCF 22R0 OHM +5% 250MI0W
R350 3093949016 1 PC RCF 33K0 OHM +5% 250MI0W
R355 4043567016 1 PC RCF 47K0 OHM +5% 250MI0W
R356 2046946016 1 PC RCF 2K2 OHM +5% 250MI0W
R357 1105958016 1 PC RCF 56R0 OHM +5% 250MI0W
R370 4043567016 1 PC RCF 47K0 OHM +5% 250MI0W
R901 6044154016 1 PC RCF 180R0 OHM +5% 250MI0W
R902 4043567016 1 PC RCF 47K0 OHM +5% 250MI0W
R961 3093951016 1 PC RCF 100K0 OHM +5% 250MI0W
R962 6044160016 1 PC RCF 68K0 OHM +5% 250MI0W
R963 3093948016 1 PC RCF 10K0 OHM +5% 250MI0W
R964 7043056016 1 PC RCF 5K6 OHM +5% 250MI0W
R965 1105964016 1 PC RCF 1K0 OHM +5% 250MI0W
R966 3093951016 1 PC RCF 100K0 OHM +5% 250MI0W
R967 8043701016 1 PC RCF 1K8 OHM +5% 250MI0W
R968 8043701016 1 PC RCF 1K8 OHM +5% 250MI0W
R969 5088300016 1 PC RCF 3K3 OHM +5% 250MI0W
R971 3093951016 1 PC RCF 100K0 OHM +5% 250MI0W
R972 3093951016 1 PC RCF 100K0 OHM +5% 250MI0W
R973 3093949016 1 PC RCF 33K0 OHM +5% 250MI0W
VR11 55250310NR 1 PC PR 50R0 OHM +20% 500MI0W
VR12 55250320NR 1 PC PR 200R0 OHM +20% 500MI0W
VR21 55250310NR 1 PC PR 50R0 OHM +20% 500MI0W
VR22 55250320NR 1 PC PR 200R0 OHM +20% 500MI0W
VR31 55250310NR 1 PC PR 50R0 OHM +20% 500MI0W
VR32 55250320NR 1 PC PR 200R0 OHM +20% 500MI0W
Miscellaneous
G101 55135980NR 1 PC TERMLUG GND
G201 55135980NR 1 PC TERMLUG GND
G301 55135980NR 1 PC TERMLUG GND
G302 55135980NR 1 PC TERMLUG GND
G303 55135980NR 1 PC TERMLUG GND
L101 55179560NR 1 PC LFA 1MM 10MM 5 LEFT 0.0MM NONE
L201 55179560NR 1 PC LFA 1MM 10MM 5 LEFT 0.0MM NONE
L301 55179560NR 1 PC LFA 1MM 10MM 5 LEFT 0.0MM NONE
N101 557207100 1 PC WIRECONASY UNIQUE 7 180MM UL1007 RIBBON 24 1
N201 556868100 1 PC WIRECONASY UNIQUE 5P 150MM UL1007 RIBBON 24 1
N301 556868300 1 PC WIRECONASY UNIQUE 4P 250MM UL1007 RIBBON 24 1
N901 556869500 1 PC WIRECONASY UNIQUE 3P 230MM UL1007 PVC DISCRETE 18 12
