Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
3 CHANNEL AMP
N902 556869600 1 PC WIRECONASY UNIQUE 2P 250MM UL1007 PVC DISCRETE 18 12
N903 556867400 1 PC WIRECONASY UNIQUE 3P 150MM UL1007 PVC DISCRETE 16 1
N904 556866000 1 PC WIRECONASY UNIQUE 2P 150MM UL1007 PVC DISCRETE 16 1
N906 555873900 1 PC POS 100R0 OHM 16.0V
NJ11 55637170NR 1 PC CONN-SPE SPEAKER TER'BOARD(2P) BK/WH D/N B30290117N
NJ21 55637180NR 1 PC CONN-SPE SPEAKER TER'BOARD(2P) BK/BU D/N B30290118N
NJ31 55637190NR 1 PC CONN-SPE SPEAKER TER'BOARD(2P) BK/BN D/N B30290119N E1474
P101 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
P106 55171540 1 PC CONN 2.0MM 7 MA ST NAT MOLEX 35336-0710 0 0
P201 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
P202 55146570 1 PC CONN 2.5MM 3 MA ST NAT 0 0
P206 55171540 1 PC CONN 2.0MM 7 MA ST NAT MOLEX 35336-0710 0 0
P301 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
P306 55171540 1 PC CONN 2.0MM 7 MA ST NAT MOLEX 35336-0710 0 0
P413 55171570 1 PC CONN 2.0MM 7 MA R NAT BD'BD SOCKET MOLEX 35237-0710 0 0
P414 55171570 1 PC CONN 2.0MM 7 MA R NAT BD'BD SOCKET MOLEX 35237-0710 0 0
P415 55171570 1 PC CONN 2.0MM 7 MA R NAT BD'BD SOCKET MOLEX 35237-0710 0 0
P802 55169140 1 PC CON 3.96MM PITCH MOREX 35313-0210
P906 55146560 1 PC CONN 2.5MM 2 MA ST NAT 0 0
W101 556871200 1 PC WIRESSTRINS 4.0 CU WIRE 78MM BK 80C Y
W102 556871200 1 PC WIRESSTRINS 4.0 CU WIRE 78MM BK 80C Y
W103 556871200 1 PC WIRESSTRINS 4.0 CU WIRE 78MM BK 80C Y
W104 556871200 1 PC WIRESSTRINS 4.0 CU WIRE 78MM BK 80C Y
B101 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B102 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B103 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B104 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B201 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B202 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B203 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B204 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B301 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B302 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B303 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
B304 5517951018 1 PC LFBEAD 44.1653OHM 100M0HZ FB-30 HC-3550
SK11 55568280NR 1 PC RELAYSGNL 24.0V 1K1OHM 5.0A
SK21 55568280NR 1 PC RELAYSGNL 24.0V 1K1OHM 5.0A
SK31 55568280NR 1 PC RELAYSGNL 24.0V 1K1OHM 5.0A
4 CHANNEL AMP
Capacitors
C409 552327300 1 PC CE 120U0F +20% 100.0V 85C
C410 552327300 1 PC CE 120U0F +20% 100.0V 85C
C411 552327300 1 PC CE 120U0F +20% 100.0V 85C
C412 552327300 1 PC CE 120U0F +20% 100.0V 85C
C509 552327300 1 PC CE 120U0F +20% 100.0V 85C
C510 552327300 1 PC CE 120U0F +20% 100.0V 85C
C511 552327300 1 PC CE 120U0F +20% 100.0V 85C
C512 552327300 1 PC CE 120U0F +20% 100.0V 85C
C609 552327300 1 PC CE 120U0F +20% 100.0V 85C
C610 552327300 1 PC CE 120U0F +20% 100.0V 85C
C611 552327300 1 PC CE 120U0F +20% 100.0V 85C
C612 552327300 1 PC CE 120U0F +20% 100.0V 85C
C709 552327300 1 PC CE 120U0F +20% 100.0V 85C
C710 552327300 1 PC CE 120U0F +20% 100.0V 85C
C711 552327300 1 PC CE 120U0F +20% 100.0V 85C
C712 552327300 1 PC CE 120U0F +20% 100.0V 85C
C401 1012100039 1 PC CE 10U0F +20% 16.0V 85C
C402 3093623071 1 PC CC 100P0F +5% -5% 50.0V NP0
C403 4043358071 1 PC CC 680P0F +10% -10% 50.0V Y5P
C404 5524629039 1 PC CE 100U0F +20% 25.0V 85C
C405 3093607071 1 PC CC 12P0F +5% -5% 50.0V NP0
C406 7042837071 1 PC CC 220P0F +10% -10% 50.0V Y5P
C407 2041669070 1 PC CPM 100N0F +20% 250.0V
C408 2041669070 1 PC CPM 100N0F +20% 250.0V
40
AVR7200 harman/kardon
