Harman Kardon AVR 7200 Service Manual

Ref
Designator
Part Number Qty Description
4 CHANNEL AMP
Semiconductors
D407 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D507 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D607 20525530NR 1 PC D-SR 1N4003 200.0V 1A
D707 20525530NR 1 PC D-SR 1N4003 200.0V 1A
Q408 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q409 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q410 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q411 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q412 55133270NR 1 PC TR-SHPLF 2SC4137 N 100MI0A 20V
Q414 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q415 55179190NR 1 PC TR-SHPLF 2SA1859A P -2.0A
Q416 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q417 55179200NR 1 PC TR-SHPLF 2SC4883A N 2.0A
Q418 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q419 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q420 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q421 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q508 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q509 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q510 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q511 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q512 55133270NR 1 PC TR-SHPLF 2SC4137 N 100MI0A 20V
Q514 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q515 55179190NR 1 PC TR-SHPLF 2SA1859A P -2.0A
Q516 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q517 55179200NR 1 PC TR-SHPLF 2SC4883A N 2.0A
Q518 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q519 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q520 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q521 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q608 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q609 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q610 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q611 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q612 55133270NR 1 PC TR-SHPLF 2SC4137 N 100MI0A 20V
Q614 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q615 55179190NR 1 PC TR-SHPLF 2SA1859A P -2.0A
Q616 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q617 55179200NR 1 PC TR-SHPLF 2SC4883A N 2.0A
Q618 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q619 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q620 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q621 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q708 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q709 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q710 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q711 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q712 55133270NR 1 PC TR-SHPLF 2SC4137 N 100MI0A 20V
Q714 55231350NR 1 PC TR-SLPLF 2SC3423Y N 50MI0A 150V
Q715 55179190NR 1 PC TR-SHPLF 2SA1859A P -2.0A
Q716 55231240NR 1 PC TR-SLPLF 2SA1360Y P -50MI0A -150V
Q717 55179200NR 1 PC TR-SHPLF 2SC4883A N 2.0A
Q718 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q719 551837900 1 PC TR-SHPLF C5200-O(AC) N 15.0A
Q720 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q721 551839300 1 PC TR-SHPLF A1943-O(AC) P -15.0A
Q401 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q402 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q403 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q404 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q405 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
Q406 5531585056 1 PC TR-SLPHF 2SA1370-E P 100MI0A 40 320
Q407 2064785056 1 PC TR-SHPLF KTA1268BL P 100MI0A 120V
Q422 2055660056 1 PC TR-SHPLF KTC3200BL N 100MI0A 120V
Q423 2050808056 1 PC TR-SLPLF KTC3198BL N 150MI0A
