Harman Advance Pellet Stove Maintenance Guide

25
Cleaning the Heat Exchanger System
1. Remove brick panel and ame guide. (See Pg 23.)
2. Remove the ash pan. See Page 20.
3. Remove ue bafes located on each side of the
burnpot, see Fig. 49 & 50. The bafe is held in place
by inserting the tab into the slot (located toward the
outside of the rebox) and resting it on the hook tab
located beside the burnpot.
4. Pull the pointed end of the bafe slightly front with
one hand while pushing up from below with the other
hand. See Fig. 50.
5. With the bafe released from the tabs, rotate the
pointed end toward the door opening. Lift bafe up
and out.
The right and left bafe are interchangeable.
6. Now remove the heat exchanger bafe plates. See
Fig. 51 & 52. To remove the left plate, slide the center
lock to the right. To remove the right plate, slide the
center lock to the left. (The right and left plates are
interchangeable.)
This will allow access to all of the rear vertical heat
exchanger surfaces.
7. With all four bafe plates removed, cleaning can be
performed with the arrow end of the scraper. See Fig.
53.
8. Scrape all of the heat exchanger surfaces. (Be sure
to clean any internal ledges where y ash could have
collected.)
Top Accordion
Heat Exchangers
Rear Firewall
Heat Exchanger
Fig. 49
Fig. 50
Fig. 51
Fig. 52
Fig. 53
Tab
Slot
Maintenance - Heat Exchanger
Center Lock
Center Lock
Hook Tab
