IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for
your appliance please provide model number and serial number. All parts listed in this manual may
be ordered from an authorized dealer.
12 Frame
Gold 3-43-06613-4
Brushed Stain 3-43-06613-7
Brushed Nickel 3-43-06613-8
13 Ash Pan Weldment 1-10-07581A
14 Door Assembly 1-10-08612A
Gasket, Door, 1 1/2” x 7/16” 2-00-71611
Gasket, Glass 1-00-11862
Glass, Large Front 3-40-08728
Glass, Side 3-40-08729
Glass Clips 1 Set 1-00-06600
15 Retainer Assembly 1-10-08553S
16 Combustion Intake Weldment 1-10-07574W
17 Side Door - Right 2-00-06610-2P
18 Distribution Blower
3-21-22647
19 Combustion Blower 3-21-08639
Fan Blade, 5” 3-20-502221
20 UL Feeder Hopper Rear Shield Left
Pre 008360001 2-00-06617P
Post 008360001 2-00-06788B
21 UL Feeder Hopper Rear Shield Right
Pre 008360001 2-00-06616P
Post 008360001 2-00-06789B
22 Pellet Tailpipe Gasket
Pkg of 5 1-00-07381
23 Pellet Tailpipe Cast 3-00-247237
Door Hinge Weldment Qty. 2 Req. 1-10-08735W
Harman Gold Label Pkg of 5 3-90-08540-5
Haman Silver Label Pkg of 5 3-90-04580-5
Spring Latch Qty. 2 Req. 3-31-00927
Thermister Probe
Pre SN 008360001
1-00-00744
Post SN 008360001
3-20-00844
Additional service parts on following page.
