The Advance pellet stove is more than just automatic ignition, it is also automatic temperature
control. The automatic system will allow the re size to be adjusted to match the heating
needs and even put the re out if necessary. If heat is needed after the re is out, the
Advance will automatically re-ignite and adjust the re size to match the heating need. The
totally automatic room sensor mode is recommended because of its efciency.
The unit can be switched between "AUTO" and "MANUAL" at any time during operation.
Room Temperature Mode: This setting will produce a room
temperature of 70 degrees with the distribution blower at
medium speed.
This setting will produce medium heat with the
distribution blower on "low".
This setting will produce continuous maximum heat
output with the distribution blower at full speed.
In "Room Temp Mode" heat output is controlled
automatically by the Room Sensing Probe. When the
Room Sensing Probe calls for heat, the stove will increase
output. When the Room Sensing Probe is getting close to
the set temperature, the stove will begin to level off output
and keep the re burning at just the right temperature to
maintain that setting.
High output is determined by the feed rate setting.
This setting, generally on #4, can be increased if higher
burn rates are necessary. The unit's maximum burn rate
should not create less than 1" of ash on the burn pot front
edge. See Fig.2, Page 5. Overfeeding is not a safety
concern, but fuel may be wasted if unburned pellets fall
into the ash pan.
In "Room Temp Mode" a constant fuel consumption
rate is sacriced for exact room temperature. Therefore,
as it gets colder more pellets will be burned automati-
cally.
The distribution blower speed will vary according to
the position of the mode selector pointer, and re size.
This allows for automatic ignition upon start-up only.
The unit can then be set at any desired setting. The heat
output and fuel consumption will remain constant regard-
less of room temperature. The unit's maximum feed rate
should not create less than 1" of ash on the burn pot front
edge. See Fig 2, Page 5.
The unit's low burn or maintenance setting is as
low as it will go. It will not go out unless it runs out of
fuel or is turned off.
To kill the re or stop burning the stove, turn the Mode
Selector to "OFF". This will cause the re to diminish and
burn out. When the re burns out and the stove cools down
everything will stop.
If you pull the plug to shut down the stove, all motors will
stop. This may cause incomplete combustion and smoke in the
rebox. If the load door is opened the smoke may escape.
The best way to shut down the stove is simply let it run
out of pellets, then the stove will shut down automatically.
