6
USER GUIDE
ZC Series Wall Controllers
Safety Warning
The installation of the Zone Controllers MUST be accomplished with the use of cable which is rated VW-1 or
higher. Common NEC designations which meet this rating include: CMP, CMR, CMG, CM and CMX.
Specifications
Connections: ZC-1, ZC-2, ZC-3, ZC-6, ZC-7, ZC-8 and ZC-9 Connectors: (2) RJ-45
ZC-4 Connectors: (2) RJ-45, (1) 6-Pin Phoenix
ZC-BOB Connectors: (7) RJ-45
ZC-Fire Connectors: (2) RJ-45, (2) 2-Pin Phoenix
Wiring: Maximum cable length depends on number of Zone Controllers and wiring
schematic.
Series Wiring: Maximum cable length varies with number of Zone Controllers. For
example, three Zone Controllers: 600 ft., six Zone Controllers: 300 ft.
Parallel Wiring: Using a ZC-BOB: Up to six Zone Controllers: 1000 ft.
Cable: CAT5 or CAT5E with <28.6 Ohm/M (Ohm/1000 ft.) nominal DCR and
rated VW-1 or higher.
Safety Agency Approvals: UL 60065-07, IEC 60065, EN 55013
Shipping Weight: .7 lb.
