Harman JBL Quantum910X - Page 5

003 OVERVIEW
01 ANC / TALKTHRU LED
02 ANC / TALKTHRU button
03 Game audio-chat balance dial
04 Volume Control
05 Detachable Windshield foam
06* Notification LED for mic mute / unmute
07* Microphone Mute / unMute
08 CHARGING LED
09 3.5 mm Audio Jack
10 USB-C port
11 Voice Focus Boom Microphone
12 SPATIAL SOUND / head tracking control
13 Power on / off and Bluetooth pairing slider
14 POWER / 2.4GHz / Bluetooth LED
15* RGB Lighting Zones
16 Flat-fold ear cup
17 2.4GHz PAIRING BUTTON
18 Volume Control
19 MIC MUTE BUTTON
*
03
04
06
13
14
12
16
15
01
07
02
09
05
10
17
18
08
11
19
