P68 Pellet Stove


1. Fines are small pieces of broken pellets (sawdust). Fines do not
ow easily and often build up on the hopper funnel bottom angles.
You can push these nes into the feeder opening and then ll the
hopper with pellets. As the system works, they will be burned. Or
you can clean them out before lling the hopper.
2. The "TEST" cycle will operate the feeder motor for exactly one
minute. Turning to "TEST" again and again may purge too much
fuel into the burn pot causing excessive smoke on start-up.
3. The rebox low pressure switch and the hopper lid position switch
will not allow the auger motor or the igniter element to operate if the
hopper, view door or the ash pan door are open.
4. Adjust Feed Rate. If this is your rst re or you are trying different
pellets, set the feed adjuster to #4, Fig. 17. This is a conservative
number and will probably need to be increased. After you know a
feed rate setting that works well, use that setting. Remember, if your
feed rate is too high you may waste fuel.
5. This is usually a weekly maintenance procedure. Cleaning the
burn pot with the scraper with a small amount of new fuel in the
bottom is not a problem. First, scrape the ashes on the front of the
burn pot into the ash pan. Then, scrape the top surface of the burn
pot downward into the base of the burn pot. When the stove is
ignited these scrapings will be pushed out by the feeder and burned.
6. The ash pan can hold the ashes from approximately 1 ton of
premium fuel. This means the ashes will only need to be emptied
a few times a year.
7. Setting the feed adjuster # for maximum burn: With the unit
burning in "AUTO", turn to "Stove Mode" and put the fan on "H".
Set the Temperature Dial to #7. Allow the unit to burn for about 30
minutes and check ash on front of burn pot. Fig. 18. If the ash line
is larger than 1", turn the feed adjuster from #4 to #5. Allow another
30 minutes of burn time and check again. If , at #6 setting, a 1" or
less ash bed is not obtainable, it is not a problem. The 1" ash bed
is only at maximum burn rate and at most normal settings the ash
bed will be larger.
Fig. 17
SeeHint #7.
Fig. 18
1"
Flame Guide

Make sure the unit is plugged into a 120 VAC,
60 HZ electrical source. The power light should be the
only light lit.


1. 
2.  with pellets.
1
3. with scraper, if necessary.
5
4.        
(for one 60 second cycle).
2
This
will feed pellets into the auger tube and also allow you
to check the motors for operation. 



5. 

6. into the "AUTO" position.
7.     to desired room
temperature.
8.  to Room Temperature or Stove
Temperature.
9.   with pellets and   as
required.
6

HOT WHILE IN OPERATION. KEEP CHILDREN,
CLOTHING AND FURNITURE AWAY.
CONTACT MAY CAUSE SKIN BURNS.

KEEP HOPPER LID, FIRE DOOR, AND
ASH DRAWER PROPERLY CLOSED WHEN
APPLIANCE IS IN OPERATION.
       
   
   

  
     



