17
PP38+ Pellet Stove
The setting above will produce continuous maximum heat
output with the distribution blower at full speed.
The setting above will produce continuous medium heat
output with the distribution blower at low speed.
In the Stove Temperature Mode, the stove can
be adjusted to the desired setting using the same
temperature control dial as is used in the Room
Temperature Mode. The heat output and fuel
consumption will remain constant regardless of room
temperature. The settings from 1 to 7 on the inner ring
of the temperature dial provide for relative heat output
settings with 1 being low and 7 being the maximum.
Never pull the plug to shut down the stove. This will
stop the combustion blower and smoke will escape
through window and door gaskets.
For most premium grade pellet fuels the Feed
Adjuster Knob should be set at 4. If higher ash fuels
are used the setting should be increased to 5 or 6. Also
higher settings are required if you would like to get the
maximum heat output from the stove. At the maximum
burn rate (with the temperature dial on 7/90° and the
feed adjuster at 6) there should be 1" or more of ash
on the front of the burn pot. If there is less than 1" of
ash, turn the feed adjuster knob down to a lower setting.
The best way to shut down the stove is to simply let it
run out of pellets. The stove will shut down automatically.
Alternatively, you can turn the Mode Selector to “off”.
This will cause the re to gradually die down and go
out. The re will not go out immediately and may take
more than an hour to fully shut down, depending on
the burn rate.
If the stove is left to run out of fuel, you may get a
6 blink status light. If this happens, simply reset the
control board by turning the mode selector to OFF and
back ON.
