01/12
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
4 Flue Tail Pipe 3-00-247237
5 Auger Motor Cover 2-00-773852P
6 Auger Motor Shield 2-00-773815P
7 Differential Switch 3-20-6866
8 Distribution Blower 3-21-22647
9 Combustion Motor 3-21-08639
10 Rear Cover Left 2-00-773828-1P
11 Rear Cover Right 2-00-773828-2P
12 Combustion Intake Weldment 1-10-08516S
13 Retainer Assembly 1-10-08533S
14 Ash Pan
Pre 10327 1-10-08508
10327 to 008080066
1-10-773873
Post 008080066 1-10-7738108A
15 Ash Door Assembly
Pre 008080066 1-10-773871
Post 008080066 1-10-7738106A
16 Bolt on Hinge Weldment 2-00-06952B
17 Cast Door Frame 4-00-06800P
18 Glass Panel 3-40-950133125
Glass Clip w/hardware (Pkg of 4)
Pre 00880001 1-00-773862
Post 00880001 1-00-249140
19
Door Handle Assembly (Contains: Paw Bolt, Wooden Handle,
Washers and Screws.)
Pre 10327 1-00-08704
Post 10327 1-00-453001
Wooden Handle, Load Door
Pre 10327 1-00-00122
Post 10327 1-00-00247
20 Burn Pot Weldment 1-10-08514
Flame Guide 3-00-08534
Clean Out Cover 2-00-06112
Thumb Screw Pkg of 10 3-31-782108-10
21 Fire Brick 4-1/2 x 9 x 1-1/4" Pkg of 7 1-00-900450125
22 Hopper Heat Shield 2-00-773854B
23 Feeder Cover 2-00-773853
24 Circuit Board
Pre 008190059 1-00-03769
Post 008190059 1-00-06142
Circuit Board Plate, Studded with Label Pre 008190059 1-10-08540
Circuit Board Label Post 008190059 3-90-08646
Knob, Contol Board/D-Shaft 25 Sets 1-00-015605
Additional service parts on following page.
