Harman Super Magnum Coal Stoker - Page 33

Service Parts
Super Mag Stoker
Beginning Manufacturing Date: July 2009
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers.Provide
modelnumberandserialnumberwhenrequestingservicepartsfromyourdealerordistributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
31 1/4”-20x1/2”AlloySteelBlackOxideButtonHeadCapScrew Pkgof100 3-30-3015-100
Y
32 6mmSpringWasher Pkgof25 3-31-08558-25
33 AirGrill 2-00-02726L
34 StandardFirebrick9”x4-1/2”x1-1/4” Pkgof7 1-00-900450125
Y
35 AngleCutBrick-Setofcutbrick 2-00-00688
Y
36 SidePanel Qty.2req. 2-00-02722B
37 BodyWeldment 1-89-02700W
38 DuctCoverWeldment 1-10-02740W
39 HopperAssembly 1-10-02733-1A
Y
40 ESPProbe 3-20-02778
Y
41 #8-18x3/4”HexWasherHeadTEKSDrillandTap Pkgof100 3-30-5003-100
Y
42 1/4-20x5/8”HexWasherSlotT23ZincThreadCuttingScrew Pkgof50 3-30-1111-50
Y
3/8”-16x1/4”AlloySteelBlackOxideCupPointSSS Pkgof25 3-30-2014-25
Y
AirGrill BrushedStainless 3-43-02726-7
AshDoorTileFrame BrushedStainless 3-43-02729-7
BallPlunger,5/16x1/2 Pkgof3 3-31-5500-3
BallSpringBracket 2-00-06714
Brick,Fullskid 414Pcs 3-40-900450-414
DoorHingew/Pin Qty2req 3-00-773813
DoorTrim BrushedStainless 3-43-06931-7
D-ShapeKnob/Shaft 25Sets 1-00-015605
Y
FemDisc-FullyIns
Pkgof25
1-00-00959 Y
FrontDoorHandle&Bolt 1-00-00247
Y
FrontDoorLatch 3-00-249119P
Y
GasketGlue,32oz 3-42-4583
Gasket,3/8RDHD 5Ft 1-00-43375
Y
Glassclipsw/Hardware Setof4 2-00-05202-4
Y
Ground Harness 3-20-02776
Label,ControlBoard 3-90-08646
Labels,Caution&Danger 10Ea 1-00-200408541
LoadDoor 4-00-06920P
LoadDoorLatchHardware 1-00-06903
PowerCordsw/Ends 3-20-39685
Y
RoomSensor 3-20-00906
Y
ThermostatExtension 3-20-00607
Y
ThermostatProbeExtension 3-20-72225 Y
TouchUpPaint,Aerosol,Black
Pre008600955
3-42-1990
Post008600955 3-42-19905
WiringHarness 3-20-02775
AdditionalServicePartsonfollowingpage
