Harrington NER2020L - Page 53

53
9.1 Housing and Motor Parts
Figure
No.
Part Name
Parts
Per
Hoist
001H
003S
003H
005S
005L
010S
010L/020C
1 Fan Cover 1 ER2BS9107 ER2CS9107 ER2CL9107 ER2DS9107 ER2CS9107
2 Fan 1 ER2BS9108 ER2CS9108 ER2CL9108 ER2DS9108 ER2CS9108
3 Snap Ring 1 9047113 9047116 9047113
4 Brake Cover 1 ER2BS9115 ER2CS9115 ER2CL9115 ER2DS9115 ER2CS9115
5 Packing B 1 ER2BS9119 ER2CS9119 ER2CL9119 ER2DS9119 ER2CS9119
6 Set Pin S 2 E6SE005S9120 ES120010S E6SE005S9120
7 Socket Bolt 4 9091234 J1BG10504522 9091234
8
Electromagnetic
Brake Assembly
1 MBABB0ENA MBABB09NA MBABB0ENA MBABB18NA MBABB09NA
9 Key B 1 ER2CL9360 ER2CS9360 ER2CL9360 ER2DS9360 ER2CS9360
10 Snap Ring 2 9047119 9047124 9047116 9047124
11 Socket Bolt 3 9091254
12
Spring Lock
Washer
3 9012709
13 V Ring 1 ER2CS9210 ER2DS9210 ER2CS9210
14
Motor Shaft With
Rotor
1 ER2BS5502 ER2CS5502 ER2CL5502 ER2DS5502 ER2DL5502
15 Ball Bearing 1 9000904 9000905 9000904 9000905
16 Ball Bearing 1 9001003 9000904 9000922
17
Motor Frame
With Stator
1 ER2BKV03S5A1 ER2BKV05S5A1 ER2BKV05L5A1 ER2BKV10S5A1 ER2BKV10L5A1
18 Packing M 1 ER2BS9118 ER2CS9118 ER2DS9118
19 Set Pin S 2 ES120003 ES120010S ER1DS9138
20 Socket Bolt 4 9091252 9091275 9091296
21 Body B 1 ER2BS61011 ER2CS61011 ER2CS9101 ER2DS9101
22 Oil Plug 1 E5FE003S9111 E5FE003S9111
23 Plug Packing 1 E3S112003
24 Snap Ring 1 9047255 9047262 9047268
25 Gear Case
S
1
ER2BS9103
ER2CS9103 ER2DS9103
D ER2BI9103
26 Oil Plug 1 E5FE003S9111
27 Plug Packing 1 E3S112003
28 Spring Pin 1 9148128 E3S129005S
29 Packing G
F 1
ER2BS9116 ER2CS9116 ER2DS9116
M 2
30 Set Pin S
F 2
E6SE005S9120
M 4
31 Socket Bolt
F 4 9091256
M 4 9091262
32
Toothed Lock
Washer
4 9679709
33 Oil Fill Plug 1 ER1BS9135
34 Eyebolt Packing 1 ES127005S
35
Name Plate Load
Side E
1 ER1BS9960
36 Oil Full Tag 1 ER1BS9953
37
Warning Decal E
(Disconnect
Power)
1 ER2CS9936
38
Name Plate OF
(Correct Oil
Required)
F
1
ER2CS9890
M ER2CS9891
39 Name Plate L AA M 1 ER1BS9893
40
Name Plate AD
(Speed Display)
1 ER1BS9868 ER1BL9868 ER1BS9868 ER1BL9868
41
Warning Decal
HW (For VFD)
D 1 ER2CI9806
42 Spacer M M 1 ER2BS9296 ER2CS9296 ER2DS9296
