HART HLPM01 User Manual

7 – English
ASSEMBLING THE GRASS CATCHER
See Figures 5 - 6.
 Placethegrasscatcherframeonaflatsurfacewiththe
handlefacingdown.
 Orientthegrasscatcherbagsothevinylfloorisfacing
up,thenslidetheframeintothebag.Wheninstalling,
allow the frame handle to remain outside the bag and
makesurethebagseamsarelocatedattheframeedges.
 Pulltheclipovertheframerailtosecureinplace.
 Liftthebag’svinylfloortothetopoftheframerailand
secureinplace.
 Using the same method, attach the remaining clips on
eachsideofthebagtotheframerailtosecure.
INSTALLING THE GRASS CATCHER (FOR
REAR BAGGING OPERATION)
See Figures 7 - 8.
NOTE: When using the grass catcher, do not install the
mulchingplug.
 Removestartkeyandbatterypack.
 Liftthereardischargedoor.
ASSEMBLY
 Lift the grass catcher by its handle and place under
the rear discharge door so that the hooks on the grass
catcherareseatedontotheslotsonthemowerhousing.
 Releasethereardischargedoor.
 Reinstallstartkeyandbatterypackwhenyouareready
tomow.
SETTING BLADE HEIGHT
See Figure 9.
When shipped, the wheels on the mower are set to a low-
cuttingposition.Beforeusingthemowerforthefirsttime,
raise the cutting position to the height best suited for your
lawn.Theaveragelawnshouldbebetween1-1/2in.to2in.
duringcoolmonthsandbetween2in.and3-1/4in.during
hotmonths.
To adjust the blade height:
 Removestartkeyandbatterypack.
 To raise the blade height, grasp the height adjustment
leverandmoveittowardthebackofthemower.
 To lower the blade height, grasp the height adjustment
leverandmoveittowardthefrontofthemower.
 Reinstallstartkeyandbatterypackwhenyouareready
tomow.
OPERATION
WARNING:
Do not allow familiarity with products to make you care-
less.Remember that a carelessfraction of asecondis
sufficienttoinflictseriousinjury.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1.Failuretodosocouldresultin
objects being thrown into your eyes resulting in possible
seriousinjury.
WARNING:
Do not use any attachments or accessories not recom-
mendedbythemanufacturerofthisproduct.Theuseof
attachments or accessories not recommended can result
inseriouspersonalinjury.
WARNING:
Before each use, inspect the entire product for damaged,
missing, or loose parts such as screws, nuts, bolts, caps,
etc.Tightensecurelyallfastenersandcapsanddonot
operate this product until all missing or damaged parts
arereplaced.Pleasecontactcustomerserviceoranau-
thorizedservicecenterforassistance.
APPLICATIONS
You may use this product for the purpose listed below:
Mowing your lawn
WARNING:
Alwaysremovebatterypackandthestartkeyfromthe
tool when you are assembling parts, making adjustments,
cleaning,orwhennotinuse.Thiswillpreventaccidental
startingthatcouldcauseseriouspersonalinjury.
INSTALLING/REMOVING BATTERY PACK
See Figure 10.
 Raisethebatterycover.
 Alignraisedribsonbatterypackwithgroovesinthebattery
portandinstallthebatterypackintothemower.
WARNING:
Make sure the latch on the bottom of the battery pack
snaps in place and the battery pack is fully seated and
secure in the mower’s battery port before beginning op-
eration. Failure to securely seat the battery pack could
cause the battery pack to fall out, resulting in serious
personalinjury.
 Lowerthebatterycover.
To remove battery pack:
 Raisethebatterycover.
 Pressandholdthebatterylatchbuttonatthebottomof
thebatterypack.
 Removebatterypackfromthemower.
Forcompletecharginginstructions, refertotheOperator’s
Manuals for your HARTbatterypackandchargermodels.

HART HLPM01 Specifications

General

Brand	HART
Model	HLPM01
Category	Lawn Mower
Language	English
