Hasselblad X1D II 50C User Manual

X1D II 50C USER GUIDE www.hasselblad.com
136
ACCESSORIES
Contents
XH LENS ADAPTER
CP.QT.00000290.01
The XH Lens Adapter can be used to mount an HC or HCD
Lens onto the X1D II Camera.
The XH Lens Adapter widens your X1D II lens choices to
include all 12 H-system HC/HCD lenses, and accessories
including a macro converter and 3 extension tubes.
The HC/HCD lens range includes a 24 mm wide-angle lens,
a 300 mm telephoto lens and a 100 mm f 2.2 lens, delivering
small depth-of-eld range and a beautiful, smooth Bokeh.
Note!
Currently the X1D II Camera supports the XH Lens Adapter
with Auto Focus for all HC/HCD Lenses, except the HC 120
Macro. Requires the X1D II to have rmware version 1.21.0 or
later. Converters and extension tubes can also be used with
AF.
Note!
Only HC/HCD lenses with rmware 18.0.0 or later can be
updated for AF functionality. Lenses with older rmware have
older hardware and cannot be updated with this rmware.
They can only be used in Manual Focus Mode.
XV LENS ADAPTER
CP.HB.00000241.01
The XV lens Adapter is used to attach Hasselblad V System
lenses to the X1D II. Compatible with all V System lenses (C,
CF, CFi, CFE, CB, F and FE)
Note!
This requires the electronic shutter function of the X1D II to be
activated. See more on page 92.
Note!
You can use Focus Peaking or 100% zoom in to assist manual
focusing.
Note!
Lens corrections for V System lenses are available with Phocus
version 3.4 or later. Note that they have to be manually
selected.
TRIPOD MOUNT RING 75MM
CP.HB.00000217.01
The tripod mount ring is designed to t the XH/XV lens
adapters and the X Converter 1.7, giving additional support
when using long or heavy HC/HCD or V System lenses on X
System camera bodies. The tripod mount ring can be tted to
1/4” and 3/8” tripod threads or the Hasselblad Quick Coupling
Plate H.

Hasselblad X1D II 50C Specifications

General

Megapixel	50 MP
Camera type	MILC Body
Sensor type	CMOS
Image sensor size	- \
Image formats supported	JPEG, RAW
Maximum image resolution	8272 x 6200 pixels
Image sensor size (W x H)	43.8 x 32.9 mm
Still image resolution(s)	-
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
Optical zoom	- x
Shooting modes	Auto, Manual
Self-timer delay	- s
Product color	Black
Battery voltage	7.27 V
Battery capacity	3400 mAh
Battery recharge time	2 h
Magnification	0.87 x
Viewfinder type	Electronic
Viewfinder resolution	3690000 pixels
Display diagonal	3.6 \
Display resolution (numeric)	2360000 pixels
Memory slots	2
Compatible memory cards	SD
Operating temperature (T-T)	-10 - 45 °C
Maximum video resolution	- pixels
Flash range (wide)	- m
Fastest camera shutter speed	1/10000 s
Slowest camera shutter speed	4080 s
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Focus adjustment	Auto/Manual

Weight and Dimensions

Depth	70 mm
Width	148 mm
Height	97 mm
Weight	650 g
Weight (including battery)	766 g
