Hasselblad X1D II 50C User Manual

X1D II 50C USER GUIDE www.hasselblad.com
138
ACCESSORIES
Contents
7.1 OPTIONAL HC LENS ACCESSORIES
H 13, 26 AND 52 EXTENSION TUBES
CP.QT.00000228.01 Extension Tube H 13 mm
CP.QT.00000223.01 Extension Tube H 26 mm
CP.QT.00000233.01 Extension Tube H 52 mm
The Extension tubes attach between the XH Lens Adapter and
the HC Lens to reduce the close focusing distance for close
up photography. They are available in three sizes: 13 mm, 26
mm and 52 mm. As the X1D II has a TTL light metering system,
exposure compensation is automatic.
CONVERTER H 1.7X
CP.QT.00000239.01
The Converter H 1.7x is mounted between the XH Lens
Adapter and the HC Lens. Then Converter H 1.7x increases the
focal length of a lens by a factor of 1.7x. It features the same
outstanding optical and mechanical quality as the elements in
the Hasselblad H-lens series.
TILT/SHIFT ADAPTER HTS 1.5X
CP.QT.00000232.01
The HTS 1.5x is designed to work with HCD24, HCD28, HC35,
HC50, HC80 and HC100 Lenses. It has a converter factor of
1.5 times and allows for +/- 10 degrees of Tilt and +/- 18 mm
Shift. AF with the X1D II works even if the adapter is set for Tilt
and/or Shift. Meta Data for Tilt and Shift amount is not added
to the image le when using the X1D II, and automatic lens
corrections will not be applied in Phocus. This is a feature
unique to the H5D and H6D Cameras.
7. 2 OPTIONAL ACCESSORIES
PRO SHADE V/H 60 – 95
CP.QT.HB000021.01
An adjustable bellows lens shade that provides highly efcient
protection against stray light. The compact, at folding design
saves space in the equipment case. It also features a lter
holder for glass, gelatin, or plastic lters.

Hasselblad X1D II 50C Specifications

General

Megapixel	50 MP
Camera type	MILC Body
Sensor type	CMOS
Image sensor size	- \
Image formats supported	JPEG, RAW
Maximum image resolution	8272 x 6200 pixels
Image sensor size (W x H)	43.8 x 32.9 mm
Still image resolution(s)	-
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
Optical zoom	- x
Shooting modes	Auto, Manual
Self-timer delay	- s
Product color	Black
Battery voltage	7.27 V
Battery capacity	3400 mAh
Battery recharge time	2 h
Magnification	0.87 x
Viewfinder type	Electronic
Viewfinder resolution	3690000 pixels
Display diagonal	3.6 \
Display resolution (numeric)	2360000 pixels
Memory slots	2
Compatible memory cards	SD
Operating temperature (T-T)	-10 - 45 °C
Maximum video resolution	- pixels
Flash range (wide)	- m
Fastest camera shutter speed	1/10000 s
Slowest camera shutter speed	4080 s
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Focus adjustment	Auto/Manual

Weight and Dimensions

Depth	70 mm
Width	148 mm
Height	97 mm
Weight	650 g
Weight (including battery)	766 g
