Hasselblad X1D II 50C User Manual

4.15 FOCUSING
AUTOFOCUS
Autofocus is activated by pressing the shutter release to the
half-press position or by pressing the AF-D button.
The operative range is from EV 1 to EV 19 at ISO 100.
Focus is determined by maximizing the contrast within the
central marked area.
Depending on situation, the indicated AF Area looks different.
See illustrations to the right and page 70.
AF Assist Light
AF Assist Light (A) is automatically activated if selected. The
operative distance is approximately up to 4 metres from the
camera.
Note!
You can select position of the AF point. See page 76.
It is also possible to choose from three different sizes. See
page 77.
Note!
H System lenses whose rmware version is older than 18.0.0
cannot be updated with AF functionality. The camera will
default to Manual Focus mode for such lenses.
Green AF indicator. AF set correct.
White AF indicator.
Red AF indicator. AF analysis failed to focus.
A
X1D II 50C USER GUIDE www.hasselblad.com
72
FUNCTIONS
Contents

Hasselblad X1D II 50C Specifications

General

Megapixel	50 MP
Camera type	MILC Body
Sensor type	CMOS
Image sensor size	- \
Image formats supported	JPEG, RAW
Maximum image resolution	8272 x 6200 pixels
Image sensor size (W x H)	43.8 x 32.9 mm
Still image resolution(s)	-
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
Optical zoom	- x
Shooting modes	Auto, Manual
Self-timer delay	- s
Product color	Black
Battery voltage	7.27 V
Battery capacity	3400 mAh
Battery recharge time	2 h
Magnification	0.87 x
Viewfinder type	Electronic
Viewfinder resolution	3690000 pixels
Display diagonal	3.6 \
Display resolution (numeric)	2360000 pixels
Memory slots	2
Compatible memory cards	SD
Operating temperature (T-T)	-10 - 45 °C
Maximum video resolution	- pixels
Flash range (wide)	- m
Fastest camera shutter speed	1/10000 s
Slowest camera shutter speed	4080 s
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Focus adjustment	Auto/Manual

Weight and Dimensions

Depth	70 mm
Width	148 mm
Height	97 mm
Weight	650 g
Weight (including battery)	766 g
