4
ASSEMBLY INSTRUCTIONS
1.
2.
#2
#1
Assemble the table tennis surface #1 and table tennis surface #2 together with hinges #6 and
screws #5 as shown below.
Remove the paper on the EVA pad #4 and stick the pad #4 to the corners
of the table tennis surface as shown below.
Put the assembled table tennis tops on the table surface carefully,position together, then clip the net
post clips and net onto the tennis surface as shown below.
Hinge (#6)
Screw (#5)
EVA Pad (#4)
Table Top #2
Table Top #1
Hinge (#6)
Screw (#5)
NOTE: Be sure to measure surface table
is to be placed on, so EVA pads #4 are
positioned to contact this surface.
1
1
2
2
NOTE: If tennis table is used over billiard table it is recommended that the EVA support block be
placed under the center of the table tennis surface for extra support.
Remove the cover on the EVA
pad and stick it inside the clips
as shown.
To Next Page
