Hatz 2L41C User Manual

Engine design 2L41C, 2M41, 2M41Z
28
HATZ
Operator’s Manual
Pos. Designation
6 1/2-inch square socket for turning the engine
7 Oil drain screw
8 Speed control lever
9 Oil filter
10 Oil drain screw (on oil sump)
11 Cooling air guide for oil cooler
12 Access cap for fuel feed pump
13 Cylinder head cover
14 Air filter housing cover
15 Lifting eye, max. load 5000 N
16 Fuel return line
17 Fuel feed line with fuel prefilter
18 Type plate
19 Silencer
20 Central connector for electrical equipment
21 Battery connections
22 Powerbox
23 Electrical maintenance switch for air filter

Hatz 2L41C Specifications

General

Engine Model	2L41C
Number of Cylinders	2
Fuel System	Direct injection
Lubrication System	Forced lubrication with gear pump
Starting System	Electric starter
Cooling System	Air-cooled
Engine Type	4-stroke diesel
