Hauck Alpha - List of Parts

6
GB
a
b
c
d
8x (1/4“ – 10mm)
4x (8mm x 30mm)
2x (1/4“x 27mm)
8x (1/4“ x 45mm)
1x
A. Frontbar
B. Upper back rest
C: Lower back rest
D: Seat
E: Footrest
F: 2 no. wooden struts
G: Right framed legs
H: Left framed legs
I: Metal rod
J: Safety belt
Fasteners:
1 no. 4 mm Allen key
a. 8 no. transverse threaded
bolts
b. 4 no. wooden dowels
c. Short metal screws
d. Long metal screws
List of parts:
A
B
C
D
E
F
G H
1x
1x
1x
1x
1x
2x
1x 1x
I
J
1x
