PArTS LIST FOr gAS TrIMMEr
Please refer to the Schematic Drawing on page 33.
N
o.
Description
1 Engine assembly
2 Screw
3 Outer hex screw
4 Flat washer
5 Throttling hand assembly
5-1 Screw
5-2 Right handle shell
5-4 Throttling line
5-4 Power wire
5-5 Wiring sheath
5-6 Throttle trigger switch
5-7 Trigger spring
5-8 Bumper bar
5-9 Gauge plate
5-10 Screw
5-11 Switch
5-12 Left handle shell
5-13 Rod spring
6 Rear drive shaft assembly
6-1 Rear drive shaft tube
6-2 Flex shaft
6-3 Washer
6-4 Flex shaft bearing
6-5 Flex shaft socket
6-6 Hex. bolt
6-7 Nut
6-8 Aluminum connection tube
6-9 Quick shift trigger
6-10 Spring
6-11 Trigger bolt
6-12 Knob
6-13 Outer hex screw
6-14 Stiffened ring
7 D-type handle assembly
N
o.
Description
7-1 Outer hex screw
7-2 D-type handle
7-3 Flat washer
7-4 Spring washer
7-5 Knob
7-6 Hex nut
8 Cutting rod assembly
8-6-1 Axle ring
8-6-2 Friction washer
8-6-3 Oil bearing
8-6-4 Bolt sleeve
8-6-5 Wool felt
8-6-6 Shaft connection
9 Cutting head assembly
9-1 Cutting head sleeve
9-2 Cutter base
9-3 Line ferrule
9-4 Spring
9-5 Line spool assembly
9-6 Nylon line
10 Knob assembly
10-1 Knob
10-2 Square head screw
10-3 Knob cap
11 Wrench
12 Safety guard assembly
12-1 Safety guard
12-2 Screw
12-3 Blade
12-4 Nylon nut
13 Nylon nut
14 Flat washer
15 Spring washer
16 Tube insert
