Position the complete handle assembly over the studs on the mower
frame (Fig.8).
Clip the bag onto the frame.
Place the completed rear bag and hook onto the roller bar end shaft.
Place locking strap from the rear bag to the center bars of the middle
handle, adjust strap for proper height so the bag does not rub the
ground while mowing or transporting.
6.
1.
2.
3.
(Fig.8)
Attaching Grass Catcher(Fig.9)
Clip onto frame
(Fig.9)
