12/20 Models 3660/3661 Page 2 of 5
RECOMMENDED TOOLS: 12" adjustable wrench, 5/32” tamper-resistant hex key wrench
(supplied).
LOCATION OF UNIT: The Model 3660/3661 36XX Hose Bib Accessory is designed to be
used with a Haws Model 36XX Outdoor Bottle Filler/Fountain pedestal. The hose bib can be
mounted in any side pedestal opening. When installing this unit, local, state or federal codes
should be adhered to. CAUTION!: This Hose Bib Accessory is not freeze resistant! To
prevent damage to the unit and a potential flooding hazard, do not install in locations that have
the potential to freeze.
SUPPLY LINE:
Where sediment or mineral content is a problem, an inlet filter is recommended. The minimum
recommended line size for the 3660/3661 is 1/2“ IPS with 30-90 psi (2-6 ATM) flowing
pressure.
INSTALLATION PROCEDURE
The model 3660/3661 Hose Bibs are designed for use with 36XX Outdoor Bottle Filler/Fountain
system. The hose bib can be installed in any side opening on the pedestal or relocated to a
different location later. Multiple hose bibs can be installed if desired.
1. Connect the hose bib to the backplate using the supplied 10-32 vandal-resistant screws
and hex wrench. Install the supplied jam nuts on the back side of the screws to prevent
loosening.
2. Attach the backplate to the pedestal using the supplied ¼-20 tamper-proof screws and
hex wrench.
3. Plumb the hose bib to the water supply using ½” IPS threaded connection using either
hard pipe or flexible tubing as desired.
4. Install supplied vacuum breaker on hose bib.
For more information about Haws products, see our website: www.hawsco.com
© 2020 Haws
®
Corporation – All Rights Reserved
HAWS
®
and other trademarks used
in these materials are the exclusive property of Haws Corporation.
