7/23 Model 8605SS Page 2 of 4
LOCATION OF UNIT: The Model 8605SS Emergency Shower & Eye/Face Wash Booth
should be installed in close proximity to potential accident areas. It should be clearly
identified free from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1” IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1” NPT. Waste outlet is 4” NPT (F).
1. No flow. 1. Check the main shut-off valve.
2. Insufficient water flow. 2. Verify minimum 30psi (2 ATM) flowing
supply line pressure.
3. Insufficient water flow on
eyewash, however, shower is
sufficient.
3. Probable clogging of flow control due
to inadequate line flushing. Unscrew
eye/face wash head and remove the
four screws to disassemble the head.
Clean flow control and reassemble
head. See SP65 Installation Drawing
for details.
4. Insufficient water flow at the
showerhead, however, eyewash
is sufficient.
4. Probable clogging of flow control inside
showerhead. Unscrew showerhead off
of elbow and clean rubber flow control.
5. Eyewash stream does not meet
desired eye level.
5. Possible blocked flow control, see
above solution. Possible non-leveled
eyewash assembly.
6. Water does not drain properly. 6. Check the main waste line of your
building to see if it does handle the
capacity required for the entire
drainage system.
For more information on Haws products, see our website: www.hawsco.com
© 2023 Haws
®
Corporation – All Rights Reserved
HAWS
®
and other trademarks used
in these materials are the exclusive property of Haws Corporation.
