Haws 8605SS - Page 4

15 1/8"
384
15 1/8"
384
18"
458mm
12 1/2"
320mm
B
B
4" NPT(F) WASTE
DRAIN COUPLING
1" NPT(F) INLET
(TOP)
A
1" NPT(F) INLET
(BOTTOM)
40 1/2"
1026mm
38 3/4"
984mm
36 3/4"
931mm
30 1/4"
768mm
DETAIL A
4X 1/2" ANCHOR
BOLT ASSEMBLY
61 1/2"
1560mm
82 1/4"
2091mm
42 1/2"
1079mm
EYE/FACE WASH
ASSEMBLY
INSTALL SHOWER
CURTAIN TO GUIDE
SECTION B-B
NOTES:
1. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL CODES SHOULD
BE ADHERED TO FOR INSTALLATIONS (LOCATIONS), WASTE AND SUPPLY
REQUIREMENTS OTHER THAN SHOWN.
2. KEEP ENTRY WAY AND INSIDE OF BOOTH CLEAR OF OBSTRUCTIONS.
3. DIMENSION MAY VARY ±1/2".
© 2023 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT
IMPROVEMENTS MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
REVISION
IR
07/11/23
1
1:50
IR
07/24/23
DRAWING TYPE:
SIZE: A
5940
BY:
SLS
INSTALLATION
DATE:
DATE:
REV. ECN:
5940
CHK'D.:
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
IR
ECN:
SHEET 1 OF 1
0580002177.D
8605SS SINGLE ENTRY STAINLESS STEEL BOOTH
PAGE 4 OF 4
PAGE 4 OF 4
