Main fuses (four-fuse fuse block - later models)
Fuse connecting Rating (amp) Circuits protected
1 and 2 35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Stop lights, reversing lights, direction indicator relay, heated rear
window, headlight dim-dip relay. These systems will only operate with
the ignition switch at position ll
3 and 4 25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Horn, headlight flasher, brake failure circuit, radio memory. These
systems operate independently of the ignition switch
5 and 6 25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Heater blower motor, windscreen wipers/ washers, instruments. These
systems will operate with the ignition switch at position I or ll
7 and 8 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Left-hand side and tail lights, instrument panel lights, headlight dim-
dip relay
Note: The fitting of additional accessories which are required to operate independently of the ignition circuit should be connected to the “4”
terminal
Line fuses (four-fuse fuse block - later models)
Rating (amp) Circuits protected
15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Right-hand side and tail lights
10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Direction indicators/hazard flashers, interior light
15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dim-dip lighting
10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Rear fog light
Fuses (twenty four-fuse fuse block)
Fuse number Rating (amp) Circuits protected
1 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Heated rear window
2 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Reversing lights, stop lights, headlight dim/dip*, direction indicator
relay
3 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Auxiliary cooling fan
4 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Headlight dim/dip*
5 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Heater blower motor, sunroof motor*
6 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Wipers/ washers
7 20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Headlight flasher, horn, anti-theft alarm*
8 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tachometer*, engine management ECU*, fuel pump relay*, anti-theft
alarm*
9 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Radio/cassette, cooling fan relay, automatic gear selector light*
10 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Radio memory*, interior light, direction indicators, hazard flasher, anti-
theft alarm LED* brake test circuit*
11 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fuel pump*
12 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Starter signal
13 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Left-hand, side and tail lights
14 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Right-hand, side and tail lights, instrument illumination
15 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Left-hand headlight main beam
16 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Right-hand headlight main beam, main beam warning light
17 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Left-hand headlight dip beam
18 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Right-hand headlight dip beam
19 20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Not used
20 15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Not used
21 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Not used
22 20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Not used
23 Not used
24 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Rear fog light
* depending on model
Bulbs Wattage Type
Headlights, LHD (except Europe - dip right) . . . . . . . . . . . . . . . . . . . . . . 50/40 415
Headlights, Europe (except France - dip vertical) . . . . . . . . . . . . . . . . . 45/40 410
Headlights, France - dip vertical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45/40 411
Sealed beam headlight units:
Sealed beam with sidelights, dip left (UK only) . . . . . . . . . . . . . . . . . 60/45 104
Sealed beam without sidelight, dip left (not UK) . . . . . . . . . . . . . . . . . 60/54 101
Auxiliary driving lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 453
Sidelights (bayonet type) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 989
Sidelights (capless type) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 501
Sidelights and front direction indicators . . . . . . . . . . . . . . . . . . . . . . . . . 21/5 380
Direction indicators - front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 382
Direction indicators - rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 382
Direction indicator side repeaters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 501
Number plate light (Saloon) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 254
Number plate light (Estate, Van and Pick-up) . . . . . . . . . . . . . . . . . . . . . 5 989
12•2 Body electrical system
