Wiring diagrams 12•27
12
Key to wiring diagrams 10 to 15 inclusive
Some of the components listed in this key may not be fitted to individual models
1 Alternator
3 Battery
4 Starter solenoid
5 Starter motor
6 Lighting switch
7 Headlight dip switch
8 Headlight dip beam
9 Headlight main beam
10 Main beam warning light
11 Sidelight - RH
12 Sidelight - LH
14 Panel illumination lights
15 Number plate illumination lights
16 Stop lights
17 Tail light - RH
18 Stop light switch (hydraulic)
18 Stop light switch (mechanical)
19 Fuse box
20 Interior light
21 Interior light switch (door)
22 Tail light - LH
23 Horn
24 Horn-push
25 Indicator flasher unit
26 Indicator switch
27 Indicator warning light
28 Front indicator light - RH
29 Front indicator light - LH
30 Rear indicator light - RH
31 Rear indicator light - LH
32 Heater switch
33 Heater motor
34 Fuel level indicator
35 Fuel level indicator tank unit
37 Windscreen wiper motor
38 Ignition switch
39 Ignition coil
40 Distributor
42 Oil pressure switch
43 Oil pressure warning light
44 No charge warning light
45 Headlight flasher switch
46 Water temperature indicator
47 Water temperature transmitter
49 Reversing light switch
50 Reversing light
56 Clock (if fitted)
57 Cigar lighter (if fitted)
60 Radio
64 Voltage stabiliser
67 Line fuse
75 Automatic transmission inhibitor switch
77 Windscreen washer motor
82 Switch illumination light
83 Induction heater and thermostat
84 Suction chamber heater
95 Tachometer
110 Indicator repeater lights
115 Heated rear screen switch
116 Heated rear screen
118 Combined windscreen washer and
wiper switch
132 Brake warning light
150 Heated rear screen warning light
152 Hazard warning light
153 Hazard warning switch
154 Hazard warning flasher unit
158 Printed circuit instrument panel
159 Brake failure test switch and warning
light
160 Brake pressure differential switch
164 Resistive cable
165 Handbrake switch
166 Handbrake warning light
168 Ignition key warning buzzer
169 Buzzer door switch
170 RH front side marker light
171 LH front side marker light
172 RH rear side marker light
173 LH rear side marker light
198 Driver’s seat belt switch
199 Passenger’s seat belt switch
200 Passenger seat switch
201 Seat belt warning gearbox switch
202 Seat belt warning light
203 Blocking diode - seat belt warning
208 Cigar lighter illumination
210 Panel illumination rheostat
211 Heater control illumination
286 Rear fog guard switch
287 Rear fog guard warning light
288 Rear fog guard light
291 Brake warning relay
314 Clock illumination
Cable colour code
When a cable has two colour code letters the first denotes the main colour and the second denotes the tracer colour.
B Black
G Green
K Pink
LG Light Green
N Brown
O Orange
P Purple
R Red
U Blue
W White
Y Yellow
