Hayward PRO GRID C9002SEP User Manual

Rev. 11/00 A © 2000 Hayward Printed in U.S.A.
PARTS
Model C9002SEP
REF.
NO.
NO.
REQ’D.
PART NO. DESCRIPTION
1
2
3
4
5
7
8
9
10
11
12
1
1
2
1
1
1
1
1
1
1
1
1
CX900G
CX900H
CX900W
CX900J
CX900D
C900F
SPX0710K
CX900DB
CX800Z2
CX250Z14
SPX605Z2
Locking Knob
O-Ring
Washer
E-Ring
Guide Cone
Tank Cover O-Ring
Pipe Plug
DE Bag Assembly
Tie Rod
1/2” Drain Plug
Drain Plug O-Ring
Directional Vent Valve w/O-Ring
(Air Relief Valve)
6 CX900B
Tank Cover w/Directional
Vent Valve (Air Relief Valve)
1
13
14
CX900K
ECX1322A
2” PVC Socket Connector,
set of 2
2
HAYWARD PRO GRID D.E. SEPARATION TANK
Pro-Grid D.E. Separation Tank Specifications
Max. Working
Pressure
Required Clearance
Side
Above
PSI
50
BAR
3.45
IN
18
IN
25
MM
457
MM
635

Hayward PRO GRID C9002SEP Specifications

General

Brand	Hayward
Model	PRO GRID C9002SEP
Category	Water Heater
Language	English
