1. Technical Data / Components of the Tool
16
Always wear personal protective clothing and safety equipment!
햴 Design and Function
GBUSA
9012 SPC 9012-1 SPC 9013 SPC
Impact mechanism Pin clutch Twin hammer Pin clutch
mechanism mechanism mechanism
Air inlet thread
1
⁄
4
˝
1
⁄
4
˝
1
⁄
4
˝
Square drive 334
Max. torque [Nm] 610 623 1400
Recommended torque [Nm] 550 550 1000
Max. loosening torque [Nm] 670 670 1800
Screw size M 16 M 16 M30
Max. free speed [rpm] 7000 7500 3800
Weight [kg] 2.5 2.5 5.4
Recommended hose diameter [mm] 10 10 13
Air consumption [l/min] 113 113 176
Working pressure [bar] 6.3 6.3 6.3
Sound pressure level Lp A [dB(A)] 87 88 90
Sound power level LpW [dB(A)] 97 98 105
Vibration acceleration [m/s
2
] 2.55 3.4 6.1
