17
MOTOR/SPUR GEAR INSTALLATION
FINISHED
12006
Make sure the gear mesh is set properly.
Double-check the motor pinion screw and the spur gear nut are
tightened firmly.
12012
12012
12011
12011
12006
12043
S100
12029
S016
S020
S020
S165
S165
