5
RUNNING YOUR CAR
5
TO TUNE THE STEERING TRIM
6
TO TUNE THE THROTTLE TRIM
The trigger is unmoved and the vehicle is static. Tune the steering trim to enable the front wheels to be aligned.
Under this case, the steering Center Point is set. You can tune this switch to obtain your desired Left/Right
steering angles.
Place the vehicle with four wheels off ground. Trim the switch and you will see the wheels run either
forwards or backwards. When the wheels are trimmed to stop, this point is throttle Center Point.
It enables you to switch the direction of the steering servo's travel.
One way is Normal position, and the other is Reverse position. Please refer to the photos below:
Nor mal Po sition Rev erse P osition
